stk::IPlatform::IEventOverrider Class Reference

Interface for a platform event overrider. More...

#include <stk_common.h>

Inheritance diagram for stk::IPlatform::IEventOverrider:

Public Member Functions
virtual bool	OnSleep (Timeout sleep_ticks)
	Called by the Kernel when it is entering a sleep mode.
virtual bool	OnHardFault ()
	Called by Kernel when hard fault happens.
virtual bool	OnException (EHwException exc_id, TId tid, const struct FaultContext *const ctx)
	Called by the platform driver during initialization to obtain global, application-defined MPU configurations.

Detailed Description

Interface for a platform event overrider.

Note

Optional. Can be used to extend functionality of default IPlatform driver handlers from the user-space.

Definition at line 1101 of file stk_common.h.

Member Function Documentation

OnException()

virtual bool stk::IPlatform::IEventOverrider::OnException ( EHwException exc_id, TId tid, const struct FaultContext *const ctx )

inlinevirtual

Called by the platform driver during initialization to obtain global, application-defined MPU configurations.

Allows user-space code to configure custom MPU regions (e.g., shared data/code sections or peripheral blocks) and enable state at system startup. Unlike per-task MPU regions set via ITask::GetMpuRegions(), configurations returned by this callback apply globally across the platform driver.

Returns

Pointer to a constant MpuConfig structure encapsulating global region descriptors and enable state, or nullptr if no custom global MPU configuration is supplied.

Note

Optional. The default implementation returns nullptr.

The underlying MpuConfig instance referenced by the returned pointer must remain valid for the duration of platform initialization (e.g., point to a static instance).

See also

MpuConfig, ITask::GetMpuRegions

Called by platform driver when hardware exception occurred.

Parameters

[in]	exc_id	Hardware exception id, see EHwException.
[in]	tid	TId of the currently active task.
[in]	ctx	FaultContext which includes hardware exception frame captured at fault entry (see hw::ExceptionFrame). PC is the true faulting instruction address; may be nullptr if unavailable.

Returns

True if event is handled otherwise False to let driver handle it.

See also

EHwException

Definition at line 1149 of file stk_common.h.

        {
            STK_UNUSED(exc_id);
            STK_UNUSED(tid);
            STK_UNUSED(ctx);
            return false;
        }

References STK_UNUSED.

OnHardFault()

virtual bool stk::IPlatform::IEventOverrider::OnHardFault ( )

inlinevirtual

Called by Kernel when hard fault happens.

Note

Normally called by Kernel when one of the scheduled tasks missed its deadline (see stk::KERNEL_HRT, IPlatform::HardFault).

Returns

True if event is handled otherwise False to let driver handle it.

Reimplemented in EventOverrider.

Definition at line 1117 of file stk_common.h.

        {
            return false;
        }

OnSleep()

virtual bool stk::IPlatform::IEventOverrider::OnSleep ( Timeout sleep_ticks )

inlinevirtual

Called by the Kernel when it is entering a sleep mode.

Returns

True if event is handled otherwise False to let driver handle it.

Reimplemented in EventOverrider.

Definition at line 1107 of file stk_common.h.

        {
            STK_UNUSED(sleep_ticks);
            return false;
        }

References STK_UNUSED.

---

The documentation for this class was generated from the following file:

• stk_common.h
