stk::hw Namespace Reference

Hardware Abstraction Layer (HAL) for architecture-specific operations. More...

Classes
class	CriticalSection
	Nestable, SMP-safe critical section that combines local interrupt masking with a global cross-core spinlock. More...
class	SpinLock
	Atomic busy-wait lock used as the global cross-core synchronisation primitive inside CriticalSection. More...
class	HiResClock
	High-resolution clock for high-precision measurements. More...

Functions
template<typename T>
static constexpr Word	PtrToWord (T *const ptr) noexcept
	Cast a pointer to a CPU register-width integer.
template<typename T>
static constexpr T *	WordToPtr (Word value) noexcept
	Cast a CPU register-width integer back to a pointer.
bool	IsInsideISR ()
	Check whether the CPU is currently executing inside a hardware interrupt service routine (ISR).
template<typename T>
static __stk_forceinline T	ReadVolatile64 (volatile const T *addr)
	Atomically read a 64-bit volatile value.
template<typename T>
static __stk_forceinline void	WriteVolatile64 (volatile T *addr, T value)
	Atomically write a 64-bit volatile value.

Detailed Description

Hardware Abstraction Layer (HAL) for architecture-specific operations.

This namespace contains low-level functions that interface directly with the CPU registers and hardware state. Implementations live in the architecture back-end headers included above and are typically written in assembly or using compiler intrinsics for maximum performance and minimum latency.

See also

IsInsideISR, GetTlsPtr, SetTlsPtr, CriticalSection, SpinLock, ReadVolatile64, WriteVolatile64

Function Documentation

IsInsideISR()

bool stk::hw::IsInsideISR

(

)

Check whether the CPU is currently executing inside a hardware interrupt service routine (ISR).

Returns

true if called from an ISR context; false if called from a normal task/thread context.

Note

Used as a guard in all ISR-unsafe kernel functions (Sleep, Delay, Yield, GetTid, etc.) to catch accidental calls from interrupt context that would deadlock the scheduler.

ISR-safe itself: may be called from any context.

References __stk_forceinline.

Referenced by stk::Kernel< TMode, TSize, TStrategy, TPlatform >::KernelService::Delay(), IsIrqContext(), IsIrqContext(), stk::Kernel< TMode, TSize, TStrategy, TPlatform >::KernelService::Sleep(), stk::Kernel< TMode, TSize, TStrategy, TPlatform >::KernelService::SleepUntil(), stk_blockpool_alloc(), stk::Kernel< TMode, TSize, TStrategy, TPlatform >::KernelService::SwitchToNext(), stk::memory::BlockMemoryPool::TimedAlloc(), stk::sync::Mutex::TimedLock(), stk::sync::SpinLock::Unlock(), stk::sync::ConditionVariable::Wait(), stk::sync::Event::Wait(), stk::sync::EventFlags::Wait(), and stk::sync::Semaphore::Wait().

Here is the caller graph for this function:

PtrToWord()

template<typename T>

constexpr Word stk::hw::PtrToWord ( T *const ptr )

staticconstexprnoexcept

Cast a pointer to a CPU register-width integer.

Template Parameters

T	The type of the object pointed to.

Parameters

[in]

ptr

The pointer to be converted.

Returns

The numeric value of the pointer as a Word.

Note

This operation is used to store pointers within task context structures or stack frames where raw register values are required.

MISRA deviation: [STK-DEV-001] Rule 5-2-7 (reinterpret_cast). This is a mechanical necessity for low-level kernel operations where the hardware requires integral values for address registers.

See also

WordToPtr

Definition at line 106 of file stk_arch.h.

{
    STK_STATIC_ASSERT(sizeof(Word) == sizeof(T *));
    return reinterpret_cast<Word>(ptr);
}

References STK_STATIC_ASSERT.

Referenced by stk::memory::MemoryAllocator::AllocateArrayT(), stk::memory::BlockMemoryPool::BuildFreeList(), stk::memory::BlockMemoryPool::Free(), stk::memory::MemoryAllocator::FreeArrayT(), stk::GetTidFromUserTask(), stk::PlatformContext::InitStackMemory(), stk::Kernel< TMode, TSize, TStrategy, TPlatform >::KernelTask::IsMemoryOfSP(), ReadVolatile64(), STK_MEMCPY(), and WriteVolatile64().

Here is the caller graph for this function:

ReadVolatile64()

template<typename T>

__stk_forceinline T stk::hw::ReadVolatile64 ( volatile const T * addr )

static

Atomically read a 64-bit volatile value.

Template Parameters

T	Must be exactly 8 bytes wide and at least 4-byte aligned (enforced by static assertions).

Parameters

[in]

addr

Pointer to the volatile 64-bit memory location.

Returns

Consistent 64-bit snapshot of the value at addr.

Note

On 64-bit architectures a single aligned load is inherently atomic, the value is read directly with no additional protocol.

On 32-bit architectures uses a lock-free hi-lo retry protocol compatible with WriteVolatile64: reads the high half, then the low half, then re-reads the high half. If the high half changed between the first and second read, a tick occurred between the two 32-bit loads and the pair is retried until a consistent snapshot is obtained. Requires that WriteVolatile64 writes hi before lo (which it does).

Requires a single writer that uses WriteVolatile64. Safe with multiple concurrent readers. Not C++ memory-model compliant, intended for bare-metal embedded use only.

MISRA deviation: [STK-DEV-002] Rule 5-2-7, 5-0-15. Required for lock-free 64-bit I/O on 32-bit architectures using a Hi-Lo retry protocol.

Warning

Not safe for read-modify-write operations. Use only for polling a value written atomically by a single producer.

See also

WriteVolatile64

Definition at line 379 of file stk_arch.h.

{
    STK_STATIC_ASSERT_N(sz, sizeof(T) == 8U);  // only 64-bit types permitted
    STK_STATIC_ASSERT_N(al, alignof(T) >= 4U); // type must be at least 4-byte aligned
    STK_STATIC_ASSERT_N(ilo, ((STK_ENDIAN_IDX_LO >= 0U) && (STK_ENDIAN_IDX_LO <= 1U)));
    STK_STATIC_ASSERT_N(ihi, ((STK_ENDIAN_IDX_HI >= 0U) && (STK_ENDIAN_IDX_HI <= 1U)));

    if __stk_constexpr_cpp17 (sizeof(void *) == 8U) // 64-bit arch: aligned 64-bit load is inherently atomic
    {
        return (*addr);
    }
    else
    {
        // 32-bit arch: split the 64-bit address into two 32-bit halves;
        // writer always updates hi before lo (see WriteVolatile64), so if hi is
        // the same before and after reading lo, no write straddled the two reads.
    #if STK_STRICT_COMPLIANCY
        const Word p_base = hw::PtrToWord(addr);
        volatile const uint32_t *const plo = hw::WordToPtr<uint32_t>(p_base + (STK_ENDIAN_IDX_LO * sizeof(uint32_t)));
        volatile const uint32_t *const phi = hw::WordToPtr<uint32_t>(p_base + (STK_ENDIAN_IDX_HI * sizeof(uint32_t)));
    #else
        volatile const uint32_t *const p_base = reinterpret_cast<volatile const uint32_t *>(addr);
        volatile const uint32_t *const plo = &p_base[STK_ENDIAN_IDX_LO];
        volatile const uint32_t *const phi = &p_base[STK_ENDIAN_IDX_HI];
    #endif

        uint32_t hi, lo;
        do
        {
            hi = (*phi);
            __stk_full_memfence();

            lo = (*plo);
            __stk_full_memfence();
        }
        while (hi != (*phi)); // hi changed: a write occurred during the read; retry

        const uint64_t result = (static_cast<uint64_t>(hi) << 32U) | static_cast<uint64_t>(lo);

        return static_cast<T>(result);
    }
}

References __stk_constexpr_cpp17, __stk_forceinline, PtrToWord(), STK_ENDIAN_IDX_HI, STK_ENDIAN_IDX_LO, STK_STATIC_ASSERT_N, and WordToPtr().

Referenced by stk::Kernel< TMode, TSize, TStrategy, TPlatform >::KernelService::GetTicks(), and stk::time::TimerHost::GetTimeNow().

Here is the call graph for this function:

Here is the caller graph for this function:

WordToPtr()

template<typename T>

constexpr T * stk::hw::WordToPtr ( Word value )

staticconstexprnoexcept

Cast a CPU register-width integer back to a pointer.

Template Parameters

T	The type of the object the resulting pointer will address.

Parameters

[in]

value

The register-width integer (Word) to be converted.

Returns

A pointer of type T* addressing the memory location specified by the value.

Note

This is the inverse of PtrToWord and is primarily used when restoring a task's context from a saved stack frame.

MISRA deviation: [STK-DEV-001] Rule 5-2-7 (reinterpret_cast). Required for restoring pointer types from numeric CPU context structures.

See also

PtrToWord

Definition at line 123 of file stk_arch.h.

{
    STK_STATIC_ASSERT(sizeof(Word) == sizeof(T *));
    return reinterpret_cast<T *>(value);
}

References STK_STATIC_ASSERT.

Referenced by stk::memory::BlockMemoryPool::BuildFreeList(), stk::GetUserTaskFromTid(), ReadVolatile64(), and WriteVolatile64().

Here is the caller graph for this function:

WriteVolatile64()

template<typename T>

__stk_forceinline void stk::hw::WriteVolatile64 ( volatile T * addr, T value )

static

Atomically write a 64-bit volatile value.

Template Parameters

T	Must be exactly 8 bytes wide and at least 4-byte aligned (enforced by static assertions).

Parameters

[in]	addr	Pointer to the volatile 64-bit memory location.
[in]	value	Value to write.

Note

On 64-bit architectures a single aligned store is inherently atomic.

On 32-bit architectures the value is split into two 32-bit half-writes. The high half is always written before the low half. This ordering is the contractual invariant that ReadVolatile64 depends on to detect a mid-write tear: if a reader observes a changed high half, it knows a write occurred and retries. Breaking this order (writing lo before hi) will corrupt concurrent reads.

A full memory fence is emitted between the two half-writes to prevent the CPU from reordering the stores.

ISR-safe: does not use a critical section.

MISRA deviation: [STK-DEV-002] Rule 5-2-7, 5-0-15. Required for lock-free 64-bit I/O on 32-bit architectures using a Hi-Lo retry protocol.

Warning

Supports only a single writer at a time. Concurrent writers on the same address will corrupt the value. Not safe for read-modify-write operations (e.g. increment); the caller must ensure exclusive write access by other means.

Not C++ memory-model compliant; intended for bare-metal embedded use only.

See also

ReadVolatile64

Definition at line 444 of file stk_arch.h.

{
    STK_STATIC_ASSERT_N(sz, sizeof(T) == 8U);  // only 64-bit types permitted
    STK_STATIC_ASSERT_N(al, alignof(T) >= 4U); // type must be at least 4-byte aligned
    STK_STATIC_ASSERT_N(ilo, ((STK_ENDIAN_IDX_LO >= 0U) && (STK_ENDIAN_IDX_LO <= 1U)));
    STK_STATIC_ASSERT_N(ihi, ((STK_ENDIAN_IDX_HI >= 0U) && (STK_ENDIAN_IDX_HI <= 1U)));

    if __stk_constexpr_cpp17 (sizeof(void *) == 8U) // 64-bit arch: aligned 64-bit store is inherently atomic
    {
        (*addr) = value;
    }
    else
    {
    #if STK_STRICT_COMPLIANCY
        const Word p_base = hw::PtrToWord(addr);
        volatile uint32_t *const plo = hw::WordToPtr<uint32_t>(p_base + (STK_ENDIAN_IDX_LO * sizeof(uint32_t)));
        volatile uint32_t *const phi = hw::WordToPtr<uint32_t>(p_base + (STK_ENDIAN_IDX_HI * sizeof(uint32_t)));
    #else
        volatile uint32_t *const p_base = reinterpret_cast<volatile uint32_t *>(addr);
        volatile uint32_t *const plo = &p_base[STK_ENDIAN_IDX_LO];
        volatile uint32_t *const phi = &p_base[STK_ENDIAN_IDX_HI];
    #endif

        // write hi first: ReadVolatile64 reads hi twice and retries if it changed,
        // so writing hi before lo ensures readers can detect a torn write.
        (*phi) = static_cast<uint32_t>(static_cast<uint64_t>(value) >> 32U);
        __stk_full_memfence();

        (*plo) = static_cast<uint32_t>(value);
    }
}

References __stk_constexpr_cpp17, __stk_forceinline, PtrToWord(), STK_ENDIAN_IDX_HI, STK_ENDIAN_IDX_LO, STK_STATIC_ASSERT_N, and WordToPtr().

Referenced by stk::Kernel< TMode, TSize, TStrategy, TPlatform >::KernelService::IncrementTicks(), and stk::time::TimerHost::UpdateTime().

Here is the call graph for this function:

Here is the caller graph for this function:
